Vortex Defender-ST™ Enclosed Solar Micro Red Dot 3 MOA

Dimensions

Defender-ST™ Enclosed Solar Micro Red Dot Dimensions (in inches)

Recommended Uses

• Self-Defense
• Military
• Recreational Shooting

Specifications

• Mounting Footprint – DeltaPoint® Pro
• Dot Size – 3 MOA Dot / 32 MOA Circle
• Dot Color – Bright Red
• Magnification – 1x
• Battery Type – CR2032
• Battery Run Time – 35,000 hrs. without solar / 150,000 hrs. with solar
• Reticle – Multi-Reticle
• Eye Relief – Unlimited
• Adjustment Graduation – 1 MOA
• Travel Per Rotation – 30 MOA
• Max Elevation Adjustment – 115 MOA
• Max Windage Adjustment – 145 MOA
• Parallax Setting – Parallax Free
• Deck Height – 7.7 mm
• Length – 1.82″

Features

• Enclosed Aluminum Housing – Durable 7075 aluminum enclosed housing protects against debris and moisture.
• Multi-Reticle – Quickly adapts to diverse shooting situations.
• SOLAR with Auto D-TEC Technology – Detects light conditions to automatically draw power from solar or battery as needed.
• Large Viewing Window – For fast target acquisition and a wide field of view.
• Aspherical Lens – Provides a distortion-free sight picture and truer colors.
• Fast-Rack™ Textured Grip – Aggressive texturing on the face of the optic for racking the slide off any surface.
• Motion Activation with 10 Minute Auto-Shutoff – Automatically activates with motion, while the 10-minute auto-shutoff helps conserve battery life.
• Button Lockout – Prevents accidental brightness adjustments during use or transport.
• Parallax Free – All red dots and holographic sights exhibit a small amount of parallax; however, this is considered negligible and will not significantly affect performance.
• Unlimited Eye Relief – Non-critical eye relief allows for rapid target acquisition.
• Side Load Battery – Enables easy battery replacement without needing to re-zero the optic.
• Waterproof – Designed to withstand harsh weather conditions.
• Fogproof – Built to perform across a wide range of temperatures.
• Shockproof – Engineered to withstand high levels of recoil and impact.

Multi-Reticle

The Defender-ST™ Enclosed Solar Micro Red Dot multi-reticle offers 3 reticle options and 12 brightness settings (10 daylight, 2 night-vision) to quickly adapt to diverse shooting situations.

What’s in The Box

• Picatinny Mount
• Custom Tool
• Rubber Cover
• Most Common Mounting Screw Sets
• CR2032 Battery
• Lens Cloth
• Glock MOS Adapter Plate
• Extended Torx^® T-10 Bit

Footprint Program

Parts Diagram
